Standard Features Standard Semi-monocoque low-corrosion stainless steel frame Standard Composite exterior body panels Standard Sedan style entrance door Standard Front & rear energy absorbing bumpers Standard Double glaze side sash for driver's & entrance doors Standard MCI exclusive spiral entrance stairway with aluminum step nosing Standard ISRI 6832 3-point driver seat Standard Scissor style powered windshield blinds Standard Remote and heated exterior mirrors Standard Keyed alike exterior door locks Standard First aid kit Standard Chemical lavatory with Granicote interior finish Standard Heavy duty SST ball lavatory dump valve Standard Additional air vent in LH front parcel rack for driver Standard Additional conditioned air vent into lavatory Standard Electric baggage door locks Standard Flat composite baggage bay floors Standard Provisions for destination sign Standard Bendix ADB22X disc brakes Standard Unitized Wheel End (UWE) bearings on all axles Standard ZF independent front and tag axle suspension system with premium Sachs shocks and wide stance drive axle suspension system Standard MCI Dynamic Suspension System (MDSS), includes full high/low rise & kneeling features Standard Variable assistance power steering Standard Steerable tag axle (passive) Standard Tag unload feature (electric) Standard Tag dump feature (manual) Standard Maintenance air supply located at the front and rear of coach Standard Doga electric windshield wipers Standard Electric Bitzer A/C compressor Standard R134a refrigerant Standard Brushless evaporator and condenser motors Standard Standard Electronic manuals only (thumb drive) Standard Automatic Traction Control System (ATC) Standard SmarTire Tire Monitoring System Standard Electronic Stability Program (ESP) Standard 6-channel Antilock Braking System (ABS) Standard Parcel Rack Tether System Standard 3-Point Passenger Seat Belts (FMVSS210) Standard Parker-Vansco Multiplexing System Standard Continental Multi-Function Instrument Panel Standard REI Entertainment system including DVD and six 15” wide screen HD monitors Standard 12V power supplies in driver's area & parcel rack Standard LED interior aisle lighting (spot lights) Standard Exterior LED lighting includes; turning indicator, marker/clearance, brake, reverse, and daytime running lights (DRL) Standard LED baggage bay lights Standard Fog lamps Standard Back-up alarm Standard Siemens ELFA-2 drive motor: 300 kW/3320 lb-ft Standard XALT 63 Ah NMC batteries: 544 kWh Standard CCS-1 DC fast charge port: 150 kW charging rate Coach Dimensions Overall length: 45.58 ft/13.80 m Wheelbase: 315 in/8.00 m Overall width: 102 in/2.59 m Height to roof hatches: 140.75 in/3.58 m Front overhang: 78.25 in/1.98 m Rear overhang: 101.25 in/2.57 m Turning radius: 41 ft/12.5 m GVWR: 54,000 lbs/24,494 kg Front GAWR: 17,000 lbs/7,711 kg Drive GAWR: 23,000 lbs/10,433 kg Tag GAWR: 16,500 lbs/7,484 kg Engine & Engine Accessories 1.01.312 SIEMENS ELFA-2 DRIVE MOTOR, 300 KW/3320 LB-FT 1.05.101 ENERGY STORAGE SYSTEM EXTENDED WARRANTY - 6 YEARS, UNLIMITED MILEAGE. CAPACITY FADE IS WARRANTED TO 70% OF BEGINNING OF LIFE (BOL) TOTAL ENERGY CAPACITY AT YEAR 6 WHEN: 1) THE BATTERY DEPTH OF DISCHARGE (DOD) DOES NOT EXCEED 33% DOD BETWEEN ON ROUTE OPPORTUNITY CHARGES, AND 2) STORAGE STATE OF CHARGE (SOC), INCLUDING BUT NOT LIMITED TO OVERNIGHT AND WEEKENDS, IS 80% OF THE TIME, AND 3) CAPACITY MEASUREMENTS ARE TAKEN FROM A BALANCED ESS, AND 4) ESS IS MAINTAINED IN THE MANNER DESCRIBED IN THE MCI SERVICE MANUAL. * Capacity fade is the relative reduction of the total amount of energy the battery system can store in a single charge for the purpose of powering the vehicle as compared to capacity at BOL. 1.05.103 PROPULSION SYSTEM (TRACTION SYSTEM, CONTROLLERS/INVERTERS AND GEAR BOX) EXTENDED WARRANTY - 5 YEARS, 250,000 MILES. GOVERNOR GOVERN SPEED - 72 MPH Axle Ratios & Axle Accessories 3.01.113 REAR AXLE - RATIO 4.7 Wheels, Wheel Accessories & Tires 3.03.106 ALCOA HUB PILOTED WHEEL POLISHED BOTH SIDES FINISHED IN 22.5 X 9.00 WITH A DURABRITE FINISH (9) 3.04.403 FACTORY SUPPLIED TIRES - MICHELIN XZA-2 ENERGY, SIZE: 315/80 R22.5,"L" - RATED, MAX 75 MPH (9) Seating & Trim 4.01.2703 56 PASS - AMAYA ALPHA MODEL PASSENGER SEATS W/3 POINT BELTS 4.02.99.10 ALPHA MCI UPHOLSTERY 4.02.112 SELF-RETRACTING FOOTRESTS (52) 4.02.127.2 SEAT AISLE LIGHTS TO RGB (RED, GREEN, BLUE) MCI SUPPLIED AND INSTALLED Passenger Accessories 4.03.103 HOSTESS TABLE - ROAD SIDE 4.03.104 HOSTESS TABLE - CURB SIDE Driver Seat & Driver Seat Options 4.04.701 ISRINGHAUSEN 6832/872 NTS HIGH BACK AIR RIDE DRIVER'S SEAT W/3-POINT BELT 4.05.203 FABRIC ARMRESTS ON ISRINGHAUSEN 6832 DRIVER'S SEAT Interior Colors & Patterns Please refer to section "Selected Upholstery / Fabrics" for details regarding upholstery. Upholstery Options - Rear Interior 4.06.500 REAR INTERIOR FABRIC Interior Flooring 4.07.202 WHITE STANDEE AREA 4.07.212 WHITE STEP NOSING 4.07.421 TARABUS FLOORING 4.07.421.006 FLOORING COLOR - TARABUS GAYA WOOD NT 4521 YELLOWSTONE Lavatory & Lavatory Accessories 5.01.202 CHEMICAL TYPE LAVATORY WITHOUT WASH BASIN Audio / Video Options 5.03.101 ENHANCED SPEAKER SYSTEM, REI 5.03.102 REI CORDLESS MICROPHONE 5.03.114 AM/FM/CD/DVD TUNER, REI 5.03.236 SIX 15" 16:9 ASPECT RATIO HD LCD MONITORS, REI 5.03.237 MEDIA PANEL, REI 5.03.238 PASSENGER SAFETY ANNOUNCEMENT SYSTEM, REI 5.03.239 360 CAMERA SYSTEM, BRIGADE 5.03.240.1 4 CHANNEL MDR CAMERA RECORDING SYSTEM Parcel Rack Options 5.04.101 PARCEL RACK DOORS 5.04.115.8 SIMULATED CARBON FIBER INTERIOR TRIM - APPLIED TO PARCEL RACK DOORS, STEPWELL TRIM & ENTRANCE DOOR UPPER PANEL (35SR026 PAINT, WTP 155 FILM, 50% GLOSS) Miscellaneous Interior 5.05.101 PASSENGER SIDE WINDOW BLINDS Wheelchair Lift STANDARD WITHOUT WHEELCHAIR LIFT Sash & Glass 6.02.102 DOUBLE GLAZED SIDE PASSENGER SASH 6.02.212 REAR EXTERIOR WINDOW Miscellaneous Exterior Accessories 6.05.101 MIRRORS, BLACK Paint & Lettering 6.07.TBA CUSTOM PAINTING AND LETTERING CUSTOM PAINT:COLOR: Lead Foot Grey 924961EF 6.07.403 EXTERIOR PAINT - WITH CLEAR COAT Decals - Interior & Exterior STANDARD SEAT RESERVATION MARKERS - ENGLISH/SPANISH/FRENCH - SHIPPED LOOSE 6.08.109 EMERGENCY EXIT DECALS - ENGLISH/SPANISH 6.08.112 LAVATORY DECALS - ENGLISH/SPANISH 6.08.203 VIN PLATE 6.08.206 EXTERIOR FLEET NUMBER(S) & LEGAL LETTERING EXTERIOR FLEET NUMBER(S)/LETTERING: Instrumentation 7.02.102 METRIC GAUGES Interior Lighting 7.03.109 LED HANDRAIL LIGHTING 7.03.110 LED STEPWELL LIGHTING 7.03.111 LED WINDOW LIGHTING 7.03.112 ENTRANCE DOOR WELCOME LIGHT (PUDDLE LIGHT) (WITH MCI LOGO) 7.03.115 INTERIOR THEME LIGHTING (RGB) (MULTI-COLORED LIGHTING) WITH AISLE STRIP LIGHTS Exterior Lighting 7.04.104 CONVERSION STYLE DOCKING LAMPS IN REAR FENDERS STANDARD CONVERSION STYLE FRONT CORNERING LAMPS STANDARD LED HEADLIGHTS 7.04.108 DRIP RAIL MOUNTED LED OVERHEAD LIGHTING Electrical & Miscellaneous Electrical Accessories 7.05.112 SECURITY START FEATURE W/ROCKER IGNITION (STEPWELL LIGHT) 7.05.128 POWER OUTLETS W/110 VOLT DUPLEX PLUGS AND TWO USB PORTS AT ALL SEATS LOCATIONS, W/4000 WATT INVERTER/BATTERY CHARGER INSTALLED IN BATTERY COMPARTMENT Air Recirculation 8.02.103 AUXILIARY PARCEL RACK A/C STANDARD REMOVABLE THEATER SEATING RETURN AIR INTAKE GRILLES Additional Standard Features & Equipment 9.01.202 SMARTIRE TIRE PRESSURE MONITORING SYSTEM User Defined Specials ES4.01.3015 PASSENGER SEATS - J4500, J4500E, J3500 COACHES ES4.04.411 DRIVERS SEAT - J4500, J4500E, J3500 COACHES ES4.06.108 FABRIC ON INTERIOR PANELS OF COACH ES7.05.194.2 PARKER MUX COACH PROGRAMMING Special-2 PSA - Delete passenger seat window side armrests. Special-3 ES7.05.207 - SMALL BACKLIT DISPLAY IN FRONT HEADER TO DISPLAY CUSTOMER SPECIFIC LOGO. ILLUMINATED WITH DIMMABLE (HIGH/LOW/OFF) LED BACKLIGHTING. Special-4 ES6.05.171.2 - Ramco exterior rear view mirrors, heated, remote, integrated turn signal with chrome heads and black arms and electronic controls for both flat mirrors and convex mirrors, LED turn signals. Special-5 ES6.05.215 - ADD FOAM TAPE TO THE UNDERSIDE OF THE SIDEWALL SUPPORT BRACKETS ('W BRACKETS") TO PREVENT RATTLING. Special-6 ES7.05.247 - INSTALL A CLEAR COVER OVER THE FRONT JUNCTION BOX ELECTRONICS (AS PER CART DESIGN) Special-7 ES6.04.119 - INCLUDE GREASABLE ENGINE COMPARTMENT DOOR LINKS (AS PER CART DESIGN) Special-8 ES6.08.228 - DECAL “CARB ZEPCERT” FOR ELECTRIC COACHES SOLD IN CALIFORNIA Selected Upholstery / Fabrics Upholstery Locations: Selected Upholstery Passenger Seats Headrest Face: Morbern Prodigy Black PRO-679 Headrest Side Boxing: Morbern Prodigy Black PRO-679 Cushion and Back Center: Morbern Prodigy Black PRO-679 Cushion and Back Outside: Morbern Prodigy Black PRO-679 Side Boxing: Morbern Prodigy Black PRO-679 Back Panel: Morbern Prodigy Black PRO-679 Seat Piping: No Seat Piping Double Stitching: No Double Stitching Diamond Stitching: Small Diamonds - Black Thread Driver's Seat Headrest: Camira Fusion NAA 184 Cushion & Back - Center: Camira Fusion NAA 184 Cushion & Back - Outside: Camira Fusion NAA 184 Side Boxing: Camira Fusion NBD 184 Back Panel: Camira Fusion NBD 184 General Interior Entrance Door: Carbon Fiber Entrance Panel Front Dash Insert: Bustextil Bolster Black 2800 34008 Front Side Modesty Panels: Bustextil Bolster Black 2800 34008 Passenger Side Modesty Panels: Bustextil Bolster Black 2800 34008 Parcel Rack Fabric (Underside): Bustextil Bolster Black 2800 34008 Sidewall: Bustextil Bolster Black 2800 34008 Ceiling: Morbern Vinyl Wave WV-209 General Interior - Rear Lavatory Door: Bustextil Bolster Black 2800 34008 Curb Side Lavatory Wall: Bustextil Bolster Black 2800 34008 Rear Enclosure Panel: Not Available with Rear Window Flooring Interior Flooring: Tarabus Flooring Gaya Wood 4521 Yellowstone
